Representative Drillhole From a Larger Program

Drillhole Program Comments

Map / Unit Number

603000005

Max Drilled Depth (m)

213.4

Max Drilled Date

19/12/1976

Cored Length

196.6

Tenement

Operator

South Australia. Department of Mines and Energy.

Target

General Comments

Dip

-90

Azimuth

Class

Mineral Water Well Petroleum Engineering Stratigraphy

Datum

GDA2020

Coordinate Source

(DISUSED) Unknown

MGA Easting

592341.34

MGA Northing

6276366.5

MGA Zone

Long Degrees

135

Long Minutes

Long Seconds

44.98

S Lat Degrees

S Lat Minutes

S Lat Seconds

54.774

Long Degrees Decimal

135.9958277

Lat Degrees Decimal

-33.6485484

Horizontal Accuracy

Map 250K

SI5307 KIMBA

Map 100K

6030 Tooligie

Map 50K

SA Geodata - Database Reference

Site No

10898

Metres From

Metres To

Map Symbol

Major Lithology

Minor Lithology

Description

Qpcb

SANDSTONE

CALCRETE

Calc sandstone (?aeolianite), calcrete

Strat Unit Name

Bridgewater Formation

Strat Unit Description

Coastal barrier and shallow sub-tidal sediments: bioclastic and aeolian cross-bedded calcarenite, palaeosol horizons, often capped by calcrete.

GIS Code

I---cb

126.3

Tbe

SANDSTONE

CLAYSTONE

Sandstone & gravel, clay, carb claystone

Strat Unit Name

Poelpena Formation

Strat Unit Description

Sand, silt, clay, carbonaceous, micaceous, pyritic, frequent interbeds of dark brown lignite.

GIS Code

eI-ibe

126.3

213.4

J-o

SANDSTONE

CLAYSTONE

Sandstone, claystone, carb claystone, lignite, minor siltst

Strat Unit Name

Polda Formation

Strat Unit Description

Sand, clayey, grey, brown and black; silt, carbonaceous, grey; clay; lignite; coal. Sandstone, conglomerate in outcrop.

GIS Code

J----o

Sample Allowed Hazard

Metres From	Metres To	Feet From	Feet To	Core Group	Library Location	Culled	Core Previously Inspected	Sample Record	Sample Returned to Library
0.00	213.40	0.00	700.13	Cutting	Tonsley	N	Y	Y	Y
16.80	20.00	55.12	65.62	Core	Tonsley	N	Y	Y	Y
20.00	31.00	65.62	101.71	Core	Tonsley	N	Y	Y	N
31.00	50.40	101.71	165.35	Core	Tonsley	N	Y	Y	N
50.40	76.40	165.35	250.66	Core	Tonsley	N	Y	Y	N
76.40	103.20	250.66	338.58	Core	Tonsley	N	Y	Y	N
103.20	108.00	338.58	354.33	Core	Tonsley	N	Y	N	N
108.00	116.60	354.33	382.55	Core	Tonsley	N	Y	N	N
116.60	136.00	382.55	446.19	Core	Tonsley	N	Y	Y	N
136.00	140.00	446.19	459.32	Core	Tonsley	N	Y	N	N
140.00	147.00	459.32	482.28	Core	Tonsley	N	Y	Y	N
147.00	153.00	482.28	501.97	Core	Tonsley	N	Y	Y	N
153.00	163.60	501.97	536.75	Core	Tonsley	N	Y	Y	N
163.60	187.00	536.75	613.52	Core	Tonsley	N	Y	Y	N
187.00	193.40	613.52	634.51	Core	Tonsley	N	Y	N	N
193.40	203.40	634.51	667.32	Core	Tonsley	N	Y	N	N
203.40	212.00	667.32	695.54	Core	Tonsley	N	Y	N	N

Summary Mineral Plots

Shortwave Infrared

Thermal Infrared

Scanned Core Imagery

Sample Number	Depth From	Depth To	Sample Source	Collected By	Date Collected
13460	16.9		Drill core	FLINT, R.B.	8/10/1980
13461	17.8			FLINT, R.B.	8/10/1980
13462	20		Drill core	FLINT, R.B.	8/10/1980
52701	24.63	24.7	Drill core	KRESS, A.G.	1/03/1977
52702	27.74	27.85	Drill core	KRESS, A.G.	20/03/1977
52703	28.75	28.86	Drill core	KRESS, A.G.	1/03/1977
52708	45.7	45.79	Drill core	KRESS, A.G.	1/04/1977
52709	56.8	56.88	Drill core	KRESS, A.G.	1/04/1977
52710	62.46	62.48	Drill core	KRESS, A.G.	1/04/1977
60481	74.65	74.72	Drill core	KRESS, A.G.	1/04/1977
60479	94.7	94.81	Drill core	KRESS, A.G.	1/03/1977
52704	126.78	126.89	Drill core	KRESS, A.G.	1/03/1977
13491	127	128	Drill core	JONG, J.	30/08/1991
52705	130.35	130.44	Drill core	KRESS, A.G.	1/03/1977
52706	144.42	144.52	Drill core	KRESS, A.G.	1/03/1977
13492	150.3		Drill core	JONG, J.	30/08/1991
2132409	154.65	155	Drill core	EXTERNAL - REFER CORE INSPECTION	20/07/2015
52707	181.84	181.98	Drill core	KRESS, A.G.	1/03/1977
13493	184.35		Drill core	JONG, J.	30/08/1991
60480	184.75	184.87	Drill core	KRESS, A.G.	1/03/1977

Document	Document ID	Information Type	Document Details	Reports Database
Envelope	08496	Geochemistry Ref.	Watson, B.L.;Sears, H.W. Polda Basin source rock studies. Data. South Australia. Department of Primary Industries and Resources. Open file Envelope 1991	SAMREF
Report Book	81/00019	Geological Log Ref.	Gatehouse, C.G. Tuckey 1. Well completion report. South Australia. Department of Mines and Energy. Report Book 1981	SAMREF
Report Book	81/00019	Master Ref.	Gatehouse, C.G. Tuckey 1. Well completion report. South Australia. Department of Mines and Energy. Report Book 1981	SAMREF
Report Book	79/00141	Palaeontology Ref.
Report Book	80/00133	Palaeontology Ref.	Cooper, B.J. Palynology of selected samples from KIMBA 1:25000 sheet Eyre Peninsula No. 2. South Australia. Department of Mines and Energy. Report Book 1980	SAMREF
Report Book	81/00019	Palaeontology Ref.	Gatehouse, C.G. Tuckey 1. Well completion report. South Australia. Department of Mines and Energy. Report Book 1981	SAMREF
Report Book	81/00019	Geophysical Log(s)	Gatehouse, C.G. Tuckey 1. Well completion report. South Australia. Department of Mines and Energy. Report Book 1981	SAMREF
Internal Docket	361/76
