Drillhole Details

Details LocationStratigraphyLithologyPetrophysics Core Details Spectral Scanning Rock Samples Historical Documents References

Representative Drillhole From a Larger Program

Drillhole Program Comments

Map / Unit Number

603000012

Max Drilled Depth (m)

368.65

Max Drilled Date

23/04/1980

Cored Length

179.2

Tenement

Operator

South Australia. Department of Mines and Energy.

Target

General Comments

Dip

-90

Azimuth

Class

Mineral Water Well Petroleum Engineering Stratigraphy

Datum

GDA2020

Coordinate Source

(DISUSED) Unknown

MGA Easting

578032.96

MGA Northing

6281298.42

MGA Zone

Long Degrees

135

Long Minutes

Long Seconds

27.984

S Lat Degrees

S Lat Minutes

S Lat Seconds

18.779

Long Degrees Decimal

135.8411067

Lat Degrees Decimal

-33.6052164

Horizontal Accuracy

Map 250K

SI5307 KIMBA

Map 100K

6030 Tooligie

Map 50K

SA Geodata - Database Reference

Site No

10905

Metres From

Metres To

Map Symbol

Major Lithology

Minor Lithology

Description

SILT

SAND

Red-bn silt, sand & calcrete

Strat Unit Name

Quaternary rocks

Strat Unit Description

Undifferentiated Quaternary rocks.

GIS Code

Tbe

SAND

CLAY (UNDIFF. ORIGIN)

Off-wh fg-mg sands & clays, trace silt

Strat Unit Name

Poelpena Formation

Strat Unit Description

Sand, silt, clay, carbonaceous, micaceous, pyritic, frequent interbeds of dark brown lignite.

GIS Code

eI-ibe

188

J-o

MUDSTONE

SANDSTONE

18-112.4 sandstone, 112.4-188 interbedded mudstone, sandstone & coal; traces muscovite & pyrite, minor claystone

Strat Unit Name

Polda Formation

Strat Unit Description

Sand, clayey, grey, brown and black; silt, carbonaceous, grey; clay; lignite; coal. Sandstone, conglomerate in outcrop.

GIS Code

J----o

188

369

CP-o

MUDSTONE

CONGLOMERATE

Conglomeratic mudstone with thin interbeds of sandstone, conglomerate, claystone & siltstone

Strat Unit Name

Coolardie Formation

Strat Unit Description

Glacial, glacially derived sediments, lithic fragments, with cobbles, pebbles, and sand fragments of igneous, metamorphic and sedimentary origin.

GIS Code

CP---o

Sample Allowed Hazard

Metres From	Metres To	Feet From	Feet To	Core Group	Library Location	Culled	Core Previously Inspected	Sample Record	Sample Returned to Library
0.00	162.00	0.00	531.50	Cutting	Tonsley	N	Y	N	N
162.00	190.00	531.50	623.36	Cutting	Tonsley	N	Y	N	N
189.00	194.00	620.08	636.48	Core	Tonsley	N	Y	N	N
194.00	199.00	636.48	652.89	Core	Tonsley	N	Y	N	N
199.00	204.00	652.89	669.29	Core	Tonsley	N	Y	N	N
204.00	209.00	669.29	685.70	Core	Tonsley	N	Y	Y	N
209.00	214.00	685.70	702.10	Core	Tonsley	N	Y	N	N
214.00	219.00	702.10	718.50	Core	Tonsley	N	Y	N	N
219.00	224.00	718.50	734.91	Core	Tonsley	N	Y	N	N
224.00	229.00	734.91	751.31	Core	Tonsley	N	Y	Y	Y
229.00	234.00	751.31	767.72	Core	Tonsley	N	Y	N	N
234.00	239.00	767.72	784.12	Core	Tonsley	N	Y	N	N
239.00	244.00	784.12	800.52	Core	Tonsley	N	Y	Y	N
244.00	249.00	800.52	816.93	Core	Tonsley	N	Y	N	N
249.00	254.00	816.93	833.33	Core	Tonsley	N	Y	N	N
254.00	261.00	833.33	856.30	Core	Tonsley	N	Y	N	N
261.00	268.00	856.30	879.27	Core	Tonsley	N	Y	N	N
268.00	275.00	879.27	902.23	Core	Tonsley	N	Y	N	N
275.00	282.00	902.23	925.20	Core	Tonsley	N	Y	N	N
282.00	289.00	925.20	948.16	Core	Tonsley	N	Y	N	N
289.00	296.00	948.16	971.13	Core	Tonsley	N	Y	N	N
295.40	297.00	969.16	974.41	Core	Tonsley	N	Y	N	N
296.00	303.00	971.13	994.09	Core	Tonsley	N	Y	N	N
297.00	304.00	974.41	997.38	Core	Tonsley	N	Y	N	N
303.00	310.00	994.09	1017.06	Core	Tonsley	N	Y	N	N
304.00	311.00	997.38	1020.34	Core	Tonsley	N	Y	N	N
310.00	317.00	1017.06	1040.03	Core	Tonsley	N	Y	N	N
311.00	318.00	1020.34	1043.31	Core	Tonsley	N	Y	N	N
317.00	324.00	1040.03	1062.99	Core	Tonsley	N	Y	N	N
318.00	325.00	1043.31	1066.27	Core	Tonsley	N	Y	N	N
324.00	331.00	1062.99	1085.96	Core	Tonsley	N	Y	Y	N
325.00	332.00	1066.27	1089.24	Core	Tonsley	N	Y	Y	N
331.00	333.20	1085.96	1093.18	Core	Tonsley	N	Y	N	N
332.00	339.00	1089.24	1112.20	Core	Tonsley	N	Y	N	N
339.00	346.00	1112.20	1135.17	Core	Tonsley	N	Y	N	N
346.00	353.00	1135.17	1158.14	Core	Tonsley	N	Y	Y	N
353.00	360.00	1158.14	1181.10	Core	Tonsley	N	Y	Y	N
360.00	367.00	1181.10	1204.07	Core	Tonsley	N	Y	N	N
367.00	368.60	1204.07	1209.32	Core	Tonsley	N	Y	N	N

Summary Mineral Plots

Shortwave Infrared

Thermal Infrared

Scanned Core Imagery

Sample Number	Depth From	Depth To	Sample Source	Collected By	Date Collected
52771	206.9		Drill core	COOPER, B.J.	23/04/1980
52772	227.3	227.35	Drill core	COOPER, B.J.	23/04/1980
13459	227.35	227.4		KWITKO, G.	4/06/1980
52773	240.7	240.75	Drill core	COOPER, B.J.	23/04/1980
52770	329.04	329.08	Drill core	KWITKO, G.	1/10/1980
13458	349.74	349.81		MCKIRDY, D.M.	24/04/1980
13457	349.74	349.81		MCKIRDY, D.M.	24/04/1980
60487	357.68	357.73	Drill core	KWITKO, G.	1/10/1980

Document	Document ID	Information Type	Document Details	Reports Database
Report Book	81/00109	Geophysical Log(s)	Kwitko, G. Lock no. 1 well completion report. South Australia. Department of Mines and Energy. Report Book 1982	SAMREF
Report Book	81/00109	Master Ref.	Kwitko, G. Lock no. 1 well completion report. South Australia. Department of Mines and Energy. Report Book 1982	SAMREF
Report Book	81/00084	Palaeontology Ref.	Cooper, B.J.;Harris, W.K.;Meyer, G.M. Late Palaeozoic Coolardie Formation, Polda Basin. South Australia. Department of Mines and Energy. Report Book 1981	SAMREF
Report Book	81/00109	Palaeontology Ref.	Kwitko, G. Lock no. 1 well completion report. South Australia. Department of Mines and Energy. Report Book 1982	SAMREF
Report Book	81/00109	Geological Log Ref.	Kwitko, G. Lock no. 1 well completion report. South Australia. Department of Mines and Energy. Report Book 1982	SAMREF
Internal Docket	695/78
