Drillhole Details

Details LocationStratigraphyLithologyPetrophysics Core Details Spectral Scanning Rock Samples Historical Documents References

Representative Drillhole From a Larger Program

Drillhole Program Comments

Map / Unit Number

533400161

Max Drilled Depth (m)

375.6

Max Drilled Date

06/08/1987

Cored Length

339.6

Tenement

Operator

South Australia. Department of Mines and Energy.

Target

General Comments

Dip

-70

Azimuth

Class

Mineral Water Well Petroleum Engineering Stratigraphy

Datum

GDA2020

Coordinate Source

MGA Easting

238454.13

MGA Northing

6477762.29

MGA Zone

Long Degrees

132

Long Minutes

Long Seconds

14.27

S Lat Degrees

S Lat Minutes

S Lat Seconds

20.957

Long Degrees Decimal

132.2372973

Lat Degrees Decimal

-31.8058213

Horizontal Accuracy

Map 250K

SH5313 FOWLER

Map 100K

5334 Coorabie

Map 50K

SA Geodata - Database Reference

Site No

873

Metres From

Metres To

Map Symbol

Major Lithology

Minor Lithology

Description

Qpcb

CALCRETE

GRAINSTONE

Calcrete and v. fine gr. grainstone

Strat Unit Name

Bridgewater Formation

Strat Unit Description

Coastal barrier and shallow sub-tidal sediments: bioclastic and aeolian cross-bedded calcarenite, palaeosol horizons, often capped by calcrete.

GIS Code

I---cb

Tun

MUDSTONE

LIMESTONE

Calc. mudstone to silty recrys. LMST

Strat Unit Name

Nullarbor Limestone

Strat Unit Description

Limestone, bioclastic, micritic. Subtidal, platformal, above fair weather wave-base.

GIS Code

em-u-n

Tuw

LIMESTONE

Fine gr. recryst. limestone

Strat Unit Name

Wilson Bluff Limestone

Strat Unit Description

Wackestone, white to grey; skeletal mudstone; rudstone and minor packstone. Locally laminations and scour channels, infilled with coarser material.

GIS Code

em-u-w

AYm

CLAY (UNDIFF. ORIGIN)

Clay with Fe oxides and gritty QTZ

Strat Unit Name

Mulgathing Complex

Strat Unit Description

Paragneiss, arenaceous and aluminous; iron formation; granitic gneiss; felsic and mafic-ultramafic volcanic and intrusive rocks. Granulite to amphibolite facies. Protoliths ~2560–2460 Ma.

GIS Code

AYm

375

AYm

GNEISS

Fine to v. coarse gr. gneiss

Strat Unit Name

Mulgathing Complex

Strat Unit Description

Paragneiss, arenaceous and aluminous; iron formation; granitic gneiss; felsic and mafic-ultramafic volcanic and intrusive rocks. Granulite to amphibolite facies. Protoliths ~2560–2460 Ma.

GIS Code

AYm

	Qualifications	Organisation	Date	Metres From	Metres To
Select	Geologist	Department for Energy and Mining	1/02/2019	0	375.60

Sample Allowed Hazard

Metres From	Metres To	Feet From	Feet To	Core Group	Library Location	Culled	Core Previously Inspected	Sample Record	Sample Returned to Library
0.00	36.00	0.00	118.11	Cutting	Tonsley	N	Y	N	N
36.00	41.00	118.11	134.51	Core	Tonsley	N	Y	N	N
41.00	46.00	134.51	150.92	Core	Tonsley	N	Y	N	N
46.00	51.00	150.92	167.32	Core	Tonsley	N	Y	N	N
51.00	56.00	167.32	183.73	Core	Tonsley	N	Y	Y	Y
56.00	61.00	183.73	200.13	Core	Tonsley	N	Y	N	N
61.00	66.00	200.13	216.54	Core	Tonsley	N	Y	Y	Y
66.00	71.00	216.54	232.94	Core	Tonsley	N	Y	Y	Y
71.00	76.00	232.94	249.34	Core	Tonsley	N	Y	N	N
76.00	81.00	249.34	265.75	Core	Tonsley	N	Y	N	N
81.00	86.00	265.75	282.15	Core	Tonsley	N	Y	Y	Y
86.00	91.00	282.15	298.56	Core	Tonsley	N	Y	Y	Y
91.00	96.00	298.56	314.96	Core	Tonsley	N	Y	N	N
96.00	101.00	314.96	331.36	Core	Tonsley	N	Y	N	N
101.00	106.00	331.36	347.77	Core	Tonsley	N	Y	N	N
106.00	111.00	347.77	364.17	Core	Tonsley	N	Y	N	N
111.00	116.00	364.17	380.58	Core	Tonsley	N	Y	Y	Y
116.00	121.00	380.58	396.98	Core	Tonsley	N	Y	Y	Y
121.00	126.00	396.98	413.39	Core	Tonsley	N	Y	Y	Y
126.00	131.00	413.39	429.79	Core	Tonsley	N	Y	Y	Y
131.00	136.00	429.79	446.19	Core	Tonsley	N	Y	Y	Y
136.00	141.00	446.19	462.60	Core	Tonsley	N	Y	Y	Y
141.00	146.00	462.60	479.00	Core	Tonsley	N	Y	N	N
146.00	151.00	479.00	495.41	Core	Tonsley	N	Y	Y	N
151.00	156.00	495.41	511.81	Core	Tonsley	N	Y	Y	N
156.00	161.00	511.81	528.22	Core	Tonsley	N	Y	Y	Y
161.00	166.00	528.22	544.62	Core	Tonsley	N	Y	Y	Y
166.00	172.00	544.62	564.30	Core	Tonsley	N	Y	N	N
172.00	179.00	564.30	587.27	Core	Tonsley	N	Y	Y	Y
179.00	184.00	587.27	603.67	Core	Tonsley	N	Y	Y	Y
184.00	190.00	603.67	623.36	Core	Tonsley	N	Y	Y	Y
190.00	196.00	623.36	643.04	Core	Tonsley	N	Y	N	N
196.00	202.00	643.04	662.73	Core	Tonsley	N	Y	Y	Y
202.00	208.00	662.73	682.41	Core	Tonsley	N	Y	Y	N
208.00	214.00	682.41	702.10	Core	Tonsley	N	Y	Y	Y
214.00	220.00	702.10	721.78	Core	Tonsley	N	Y	N	N
220.00	226.00	721.78	741.47	Core	Tonsley	N	Y	Y	N
226.00	232.00	741.47	761.15	Core	Tonsley	N	Y	Y	Y
232.00	238.00	761.15	780.84	Core	Tonsley	N	Y	Y	N
238.00	244.00	780.84	800.52	Core	Tonsley	N	Y	Y	Y
244.00	250.00	800.52	820.21	Core	Tonsley	N	Y	Y	Y
250.00	256.00	820.21	839.90	Core	Tonsley	N	Y	Y	Y
256.00	262.00	839.90	859.58	Core	Tonsley	N	Y	Y	Y
262.00	268.00	859.58	879.27	Core	Tonsley	N	Y	Y	Y
268.00	274.00	879.27	898.95	Core	Tonsley	N	Y	Y	Y
274.00	280.00	898.95	918.64	Core	Tonsley	N	Y	Y	Y
280.00	284.40	918.64	933.07	Core	Tonsley	N	Y	N	N
284.40	289.00	933.07	948.16	Core	Tonsley	N	Y	N	N
289.00	295.00	948.16	967.85	Core	Tonsley	N	Y	Y	Y
295.00	301.00	967.85	987.53	Core	Tonsley	N	Y	Y	Y
301.00	307.00	987.53	1007.22	Core	Tonsley	N	Y	Y	Y
307.00	313.00	1007.22	1026.90	Core	Tonsley	N	Y	Y	Y
313.00	319.00	1026.90	1046.59	Core	Tonsley	N	Y	Y	Y
319.00	325.00	1046.59	1066.27	Core	Tonsley	N	Y	Y	Y
325.00	331.00	1066.27	1085.96	Core	Tonsley	N	Y	N	N
331.00	337.00	1085.96	1105.64	Core	Tonsley	N	Y	Y	Y
337.00	343.00	1105.64	1125.33	Core	Tonsley	N	Y	Y	Y
343.00	349.00	1125.33	1145.01	Core	Tonsley	N	Y	Y	Y
349.00	355.00	1145.01	1164.70	Core	Tonsley	N	Y	Y	Y
355.00	361.00	1164.70	1184.38	Core	Tonsley	N	Y	Y	Y
361.00	367.00	1184.38	1204.07	Core	Tonsley	N	Y	Y	N
367.00	373.00	1204.07	1223.75	Core	Tonsley	N	Y	Y	Y
373.00	375.60	1223.75	1232.28	Core	Tonsley	N	Y	Y	Y

Summary Mineral Plots

Shortwave Infrared

Thermal Infrared

Scanned Core Imagery

Sample Number

Depth From

Depth To

Sample Source

Collected By

Date Collected

Geochem Results

Petrology Results

Biostrat Results

Geochron Results

48043

52.08

Drill core

DALY, S.J.

27/11/1987

3725

Drill core

DALY, S.J.

27/11/1987

48044

54.92

Drill core

DALY, S.J.

27/11/1987

48045

64.18

64.24

Drill core

DALY, S.J.

27/11/1987

48046

65.14

65.21

Drill core

DALY, S.J.

27/11/1987

61261

68.36

68.4

Drill core

DALY, S.J.

27/11/1987

48047

82.93

82.94

Drill core

DALY, S.J.

27/11/1987

48048

84.12

84.18

Drill core

DALY, S.J.

27/11/1987

3726

Drill core

DALY, S.J.

27/11/1987

48049

88.58

88.66

Drill core

DALY, S.J.

27/11/1987

3727

116

117

Drill core

DALY, S.J.

27/11/1987

48051

116.42

116.49

Drill core

DALY, S.J.

27/11/1987

48008

120.4

MARTIN, A.R.

16/06/1987

2115498

120.7

121

A full face slice of core

REID, A.J.

11/02/2015

2115499

122.1

122.3

A full face slice of core

REID, A.J.

11/02/2015

48050

122.5

122.56

Drill core

DALY, S.J.

27/11/1987

2115500

122.6

122.8

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

2115501

124

126

A full face slice of core

REID, A.J.

11/02/2015

48052

126.09

126.13

Drill core

DALY, S.J.

27/11/1987

48009

126.8

MARTIN, A.R.

16/06/1987

48117

128

128.9

Drill core

DALY, S.J.

28/04/1988

48053

130.15

Drill core

DALY, S.J.

27/11/1987

48054

130.22

130.26

Drill core

DALY, S.J.

27/11/1987

48065

132.76

132.8

Drill core

DALY, S.J.

27/11/1987

48010

138.8

MARTIN, A.R.

16/06/1987

647161

140.2

140.3

Drill core

EXTERNAL - REFER CORE INSPECTION

5/07/2004

2115502

140.2

140.4

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

48055

146.45

146.49

Drill core

DALY, S.J.

27/11/1987

2115503

146.5

146.65

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

48011

147.9

MARTIN, A.R.

16/06/1987

2115504

148

148.15

A full face slice of core

REID, A.J.

11/02/2015

48012

153

MARTIN, A.R.

16/06/1987

215772

154.8

156.4

Drill core

DALY, S.J.

647162

159.05

159.15

Drill core

EXTERNAL - REFER CORE INSPECTION

5/07/2004

48056

160

160.05

Drill core

DALY, S.J.

27/11/1987

3728

160

161

Drill core

DALY, S.J.

27/11/1987

2115505

160.1

160.35

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

60088

160.62

160.67

Drill core

DALY, S.J.

27/11/1987

647163

178.3

178.4

Drill core

EXTERNAL - REFER CORE INSPECTION

5/07/2004

3729

183

184

Drill core

DALY, S.J.

27/11/1987

2116251

183

184

Drill core

REID, A.J.

23/02/2015

48057

183.7

183.75

Drill core

DALY, S.J.

27/11/1987

48066

198.64

198.69

Drill core

DALY, S.J.

27/11/1987

2115506

207.7

208

A full face slice of core

REID, A.J.

11/02/2015

48067

209.35

209.39

Drill core

DALY, S.J.

27/11/1987

2115507

221.3

221.6

A full face slice of core

REID, A.J.

11/02/2015

3730

230

231

Drill core

DALY, S.J.

27/11/1987

2116252

230

231

Drill core

REID, A.J.

23/02/2015

48058

230.12

230.2

Drill core

DALY, S.J.

27/11/1987

2115508

236.7

237

A full face slice of core

REID, A.J.

11/02/2015

2115509

243.2

243.35

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

48059

243.23

243.28

Drill core

DALY, S.J.

27/11/1987

48068

245.25

245.3

Drill core

DALY, S.J.

27/11/1987

48060

246.5

246.55

Drill core

DALY, S.J.

27/11/1987

60087

250.56

250.63

Drill core

DALY, S.J.

27/11/1987

3731

252

253

Drill core

DALY, S.J.

27/11/1987

48061

252.82

252.9

Drill core

DALY, S.J.

27/11/1987

48069

261.77

261.81

Drill core

DALY, S.J.

27/11/1987

3732

263

264

Drill core

DALY, S.J.

27/11/1987

48062

263.62

263.69

Drill core

DALY, S.J.

27/11/1987

48071

265.62

265.67

Drill core

DALY, S.J.

27/11/1987

48063

273.18

273.26

Drill core

DALY, S.J.

27/11/1987

647164

277.7

277.8

Drill core

EXTERNAL - REFER CORE INSPECTION

5/07/2004

2115510

278.25

278.4

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

48064

278.3

278.34

Drill core

DALY, S.J.

27/11/1987

2116253

293

294

Drill core

REID, A.J.

23/02/2015

3750

293

294

Drill core

DALY, S.J.

27/11/1987

48072

293.94

293.98

Drill core

DALY, S.J.

27/11/1987

48073

295.19

295.23

Drill core

DALY, S.J.

27/11/1987

60089

295.27

295.31

Drill core

DALY, S.J.

27/11/1987

48075

300.9

300.98

Drill core

DALY, S.J.

27/11/1987

647165

306.1

306.2

Drill core

EXTERNAL - REFER CORE INSPECTION

5/07/2004

3751

307

308

Drill core

DALY, S.J.

27/11/1987

2116254

307

308

Drill core

REID, A.J.

23/02/2015

2115511

307.3

307.65

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

60090

307.71

307.76

Drill core

DALY, S.J.

27/11/1987

2115512

312

312.3

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

2115513

317.7

317.9

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

48076

317.87

317.94

Drill core

DALY, S.J.

27/11/1987

2116255

320

321

Drill core

REID, A.J.

23/02/2015

3753

320

321

Drill core

DALY, S.J.

27/11/1987

48077

320.88

320.92

Drill core

DALY, S.J.

27/11/1987

2115514

321.8

323

A full face slice of core

REID, A.J.

11/02/2015

60091

331.26

332.32

Drill core

DALY, S.J.

27/11/1987

2115515

336.5

336.8

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

647166

338.1

338.2

Drill core

EXTERNAL - REFER CORE INSPECTION

5/07/2004

3754

339

340

Drill core

DALY, S.J.

27/11/1987

2116256

339

340

Drill core

REID, A.J.

23/02/2015

48078

339.13

339.18

Drill core

DALY, S.J.

27/11/1987

3755

348

349

Drill core

DALY, S.J.

27/11/1987

48079

348.44

348.49

Drill core

DALY, S.J.

27/11/1987

48080

353.9

353.95

Drill core

DALY, S.J.

27/11/1987

2116257

359

360

Drill core

REID, A.J.

23/02/2015

3756

359

360

Drill core

DALY, S.J.

27/11/1987

48081

359.32

359.37

Drill core

DALY, S.J.

27/11/1987

2115516

366.1

366.25

A full face slice of core

EXTERNAL - REFER CORE INSPECTION

11/02/2015

48082

367.13

367.17

Drill core

DALY, S.J.

27/11/1987

647167

374.3

374.4

Drill core

EXTERNAL - REFER CORE INSPECTION

5/07/2004

48083

374.42

374.46

Drill core

DALY, S.J.

27/11/1987

3733

DALY, S.J.

27/11/1987

Document	Document ID	Information Type	Document Details	Reports Database
Report Book	89/00039	Geochronology Ref.	Daly, S.J. SADME Nundroo 1, 2 and 3 well completion report. South Australia. Department of Mines and Energy. Report Book	SAMREF
Report Book	89/00039	Geological Log Ref.	Daly, S.J. SADME Nundroo 1, 2 and 3 well completion report. South Australia. Department of Mines and Energy. Report Book	SAMREF
Report Book	89/00039	Master Ref.	Daly, S.J. SADME Nundroo 1, 2 and 3 well completion report. South Australia. Department of Mines and Energy. Report Book	SAMREF
Report Book	89/00039	Petrology Ref.	Daly, S.J. SADME Nundroo 1, 2 and 3 well completion report. South Australia. Department of Mines and Energy. Report Book	SAMREF
Internal Docket	646/75
